Determining Optimization of Factors Affecting Biogas Production by Co-digestion of Sweet Corncob Waste with Wastewater using Response Surface Methodology

Authors

  • Jutaporn Chanathaworn
  • Churat Thararux
  • Jiraporn Paoaiang

Keywords:

Co-digestion, Biogas production, Anaerobic digestion, Response surface methodology

Abstract

The objective of this study was to investigate the optimum conditions for biogas production by co-digestion of wastewater with sweet corncob waste (SW) in a 1 L batch reactor using a response surface methodology (RSM) experimental design. With three experimental factors affecting the production of biogas including the ratio of wastewater from sweet corncob milling process (WM) and wastewater from production process (WP) (WM:WP; 0:100, 20:80, 50:50, 80:20 and 100:0), total solid of substrate (TS, 8-16%) and initial pH (6 - 8) were studied. A quadratic model was used for the prediction of biogas production by central composite design (CCD). Probability (P<0.05) showed a very significance for the regression model with the R2 = 0.987. The model could be efficiently used for predicting biogas production from co-digestion. The analysis of variance indicated that all of the factors had significant individual effect on biogas production. The optimum conditions were found to be as follows: TS of substrate, 10%; initial pH, 7.0; WM:MP ratio, 50:50. The maximum biogas production was approximately 6,125 mL (7.56 mLCH4/gCODremoved.day of methane yield). The RSM technique was useful to predict the biogas production process in this study successfully.

References

Ali, S.R., Pankaj, T. and Vaibhav, V.G. (2015). Extraction of oil from rubber seeds for biodiesel application: Optimization of parameters, Fuel, Vol. 150, pp. 636-644.

Isci, A. and Demirer, G.N. (2007). Biogas production potential from cotton wastes, Renewable Energy, Vol. 32, pp. 750-757.

Rajendra, S., Amrit, B.K. and Jagan, N.S. (2008). Production of biogas from poultry waste, International Journal of Renewable Energy, Vol. 3(1), pp. 1-20.

Jha, A.K., Li, J., Nies, L. and Zhang, L. (2011). Research advances in dry anaerobic digestion process of solid organic wastes, African Journal of Biotechnol, Vol. 10(65), pp. 14242-14253.

Valentine, N.N., Brandon, G., Jay, Y., Robert, G., Darrell, V., Tim, M. and Xiying, H. (2015). Bioaugmentation with an anaerobic fungus in a two-stage process for biohydrogen and biogas production using corn silage and cattail, Bioresource Technology, Vol. 185, pp. 79-88.

Weizhang, Z., Zhongzhi, Z., Yijing, L., Wei, Q., Meng, X. and Min, Z. (2012). Productivity by co-digesting taihu blue algae with corn straw as an external carbon source, Bioresource Technology, Vol. 114, pp. 281-286.

Baccay, R.A. and Hashimoto, A.G. (1984). Acidogenic and methanogenic fermentation of causticized straw, Biotechnology and Bioengineering, Vol. 26(8), pp. 885-891.

Farooq, M., Chaudhry, I.A., Hussain, S., Ramzan, N. and Ahmed, M. (2012). Biogas up gradation for power generation applications in Pakistan, Journal of Quality and Technology Management, Vol. 8, pp. 107-118.

Picanco, A.P. , Vallero, M.V.G., Gianotti, E.P., Zaiat, M. and Blundi, C.E. (2001). Influence of porosity and composition of supports on the methanogenic biofilm characteristics developed in a fixed bed anaerobic reactor, Water Science and Technology, Vol. 44, pp. 197-204.

Sakar, S., Yetilmezsoy, K. and Kocak, E. (2009). Anaerobic digestion technology in poultry and livestock waste treatment: A literature review, Waste Management and Research, Vol. 27(1), pp. 3-18.

Alissara, R., Sakchai, P. and Sureewan, S. (2012). Optimization of key factors affecting methane production from acidic effluent coming from the sugarcane juice hydrogen fermentation process, Energies, Vol. 5, pp. 4746-4757.

APHA. (1998). Standard methods for the examination of water and wastewater, 20th ed. American Public Health Association, Washington, DC.

Singh, S.P. and Prerna, P. (2009). Review of recent advances in anaerobic packed-bed biogas reactors, Renewable and Sustainable Energy Reviews. Vol. 13, 1569-1575.

Tengku, R.T.Y., Hasfalina, C.M., Nor, A.A.R. and Halimatun, S.H. (2014). Optimization of methane gas production from co-digestion of food waste and poultry manure using artificial neural network and response surface methodology. Journal of Agricultural Science, Vol. 6(7), pp. 27-37.

Wahid, Z. and Nadir, N. (2013). Improvement of one factor at a time through design of experiments, World Applied Sciences Journal, Vol. 21, pp. 56-61.

Amari, A., Gannouni, A., Chlendi, M. and Bellagi, A. (2008). Optimization by response surface methodology (RSM) for toluene adsorption onto prepared acid activated clay, The Canadian Journal of Chemical Engineering, Vol. 86, pp. 1093-1102.

Khan, M.A, Yusup, S. and Ahmad, M.M. (2010). Acid esterification of a high free fatty acid crude palm oil and crude rubber seed oil blend: Optimization and parametric analysis, Biomass Bioenerg, Vol. 34, pp. 1751-6.

Adewoye, T.L. and Ogunleye, O.O. (2012) Optimization of neem seed oil extraction process using response surface methodology, Journal of Natural Sciences Research, Vol. 6, pp. 66-76.

Debabrata, M., Jyoti, P.S. and Susmita, D. (2012).Optimization of process parameters for the economical generation of biogas from raw vegetable wastes under the positive influence of plastic materials using response surface methodology, Journal of Biochemical Technology, Vol. 4(1) pp. 549-553.

Naphat, P. (2012). Methane production from the effluent of bio-hydrogen fermentation process by anaerobic sludge using statistical method, Pathumwan Academic Journal, Vol. 4, pp. 22-30.

Borja, R.B., Rincon, F., Raposo, J. and Martin, A. (2002). A study of anaerobic digestibility of two-phases olive mill solid waste (OMSW) at mesophilic temperature, Process Biochemistry, Vol. 38, pp. 733 -742.

Murto, M., Bjornsson, L. and Mattiasson, B. (2004). Impact of food industrial waste on anaerobic co-digestion of sewage sludge and pig manure, Journal of Environmental Management, Vol. 70, pp. 101-107.

Mararita, A.D., Spyros, N.D., Katerina, S., Constantina, Z. and Michael, K. (2010). Exploitation of olive mill wastewater and liquid cow manure for biogas production, Waste Management, Vol. 30, pp. 1841-1848.

Liu, C.F., Yuan, X.Z., Zeng, G.M., Li, W.W. and Li, J. (2008). Prediction of methane yield at optimum pH for anaerobic digestion of organic fraction of municipal solid waste, Bioresource Technology, vol. 99, pp. 882-888.

Downloads

Published

1 May 2018

How to Cite

Chanathaworn, J., Thararux, C., & Paoaiang, J. (2018). Determining Optimization of Factors Affecting Biogas Production by Co-digestion of Sweet Corncob Waste with Wastewater using Response Surface Methodology. Journal of Renewable Energy and Smart Grid Technology, 13(1). Retrieved from https://ph01.tci-thaijo.org/index.php/RAST/article/view/65162

Issue

Vol. 13 No. 1 (2018): January-June 2018

Section

Articles
