The Heat Treatment Factors Affecting AISI 304 Austenitic Stainless Steels with Wear-resistant in High Temperature and High acid Conditions for using in Agricultural Product Processing

Article Sidebar

PDF
Published: Jun 17, 2021
DOI: https://doi.org/10.14456/nuej.2021.1
Keywords:
AISI 304 Stainless Steel Heat Treatment Wear Resistant Factorial Design Food machinery

Main Article Content

Tannachart Wantang
Department of Production Engineering and Management, Faculty of Agricultural Technology and Industrial Technology, Phetchabun Rajabhat University, Phetchabun, Thailand.
Wittaya Nuchangsing
Department of Production Engineering and Management, Faculty of Agricultural Technology and Industrial Technology, Phetchabun Rajabhat University, Phetchabun, Thailand.

Abstract

This research was aimed to study factors affecting heat treatment of AISI 304 austenitic stainless steel under high natural acidity and high temperature conditions for using in the agricultural product processing which affect the weight loss after the experiment. This research applied the 23 factorial design consisting of 3 independent factors, including temperatures, holding time, and quenching fluids. In each factor, there are two experimental levels: temperature factor levels at 560 °C and 650 °C, the holding time of 20 and 40 minutes and the quenching fluids: cold water and heat-treatment oil. The Pin-on-Disc method was applied to determine the weight loss. The experimental conditions in this study were the temperatures of 70 - 80 °C and natural acidity at pH 3 - 3.5. The study found that all factors statistically significantly affected the weight loss of the stainless steel and the temperature of 650 °C, the holding time of 40 minutes and cooling in water was the most weight loss resistance. Moreover, there was a interaction of the factors, the temperatures and holding time, which affect the weight loss, and they were also significantly statistically. A mathematical model for lost weight estimation from the independent variables was formulated. The results showed that there was a 95% confidence interval, equivalent to ±0.00623 g. of the weight loss value.

Article Details

How to Cite
Wantang, T., & Nuchangsing, W. (2021). The Heat Treatment Factors Affecting AISI 304 Austenitic Stainless Steels with Wear-resistant in High Temperature and High acid Conditions for using in Agricultural Product Processing . Naresuan University Engineering Journal, 16(1), 1–6. https://doi.org/10.14456/nuej.2021.1
Issue
Vol. 16 No. 1 (2021): January-June
Section
Research Paper

References

ASTM G99-17. (2017). Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus. ASTM International.

ASTM International. (2014). Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus: ASTM G99-04. West Conshohocken.

Badischa, E., Winkelmanna, H., & Franek, F. (2009). High-temperature cyclic impact abrasion testing: wear behavior of single and multiphase materials up to 750 °C. Estonian Journal of Engineering, 15(4), 359-316.

Boonjubut, K., & Wantang, T. (2014). Study of factors affecting artificial and aging of 6061 aluminium alloy by factorial design: Proceedings of a SIBR- RDINRRU in Hong Kong, 3(2014),62-70.https://search.proquest.com/openview/cf1c22c5b4b25b52953e5a7f95c45f2e/1?pqorigsite=gscholar&cbl=2032316

Essoussi, H., Elmouhri, S., Ettaqi, S., & Essadiqi, E. (2018). Heat treatment effect on mechanical properties of AISI 304 austenitic stainless steel. Procedia Manufacturing, 32, 883-888.

He, Q., Li, A., Qu, W., Zhang, Y., Wang, T., & Kong, L. (2018). Investigation on friction and wear properties of high-temperature bearing steel 9Cr18Mo. Materials Research, 21(3), 1-8.

Jozefa, P., Mareka, V., Tomasa, V., Petera, P., & Borisa, P. (2020). Using multi-criteria analysis to evaluate the impact of drag-finishing technological parameters on the carbide tool radius. Materials Today, 22, 205-211.

Kennedy, F. E., & Lu, Y. (2015). Ian Baker Contact temperatures and their influence on wear during pin-on-disk tribotesting. Tribology International, 82, 534-542.

Khana, S. A., Shamaila, S., Anwarb, S., Hussaina, A., Ahmadb, S., & Salehb, M. (2020). Wear performance of surface treated drills in high speed drilling of AISI 304 stainless steel. Journal of Manufacturing Processes, 58, 223–235.

MA, D., Chi, H., Zhou, J., & Yong, Q. (2012). Microstructure and mechanical properties of martensitic stainless steel 6Cr15MoVn. Journal of Iron and Steel Research International, 19(3), 56-61.

Montgomery, D. C. (2013). Design and Analysis of Experiment (8th ed.). John Wiley & Son.

Olofsson, U., Tu, M., Nosko, O., Lyu, Y., & Dizdar, S. (2018). A pin-on-disc study of airborne wear particle emissions from studded tyre on concrete road contacts. Wear, 410, 165-172.

Petpadap, P., Dejang, N., & Maneerung, A. (2018). Arm press design of Pin-on-Disc wear testing machine and wear testing of stainless steel 304. Burapha Science Journal, 23(3), 1481-1492.https://www.semanticscholar.org/paper/Arm-Press-Design-of-Pin-on-Disc-Wear-Testing-and-of-PetpadapDejang/fabb8d08dc496f15e654b0c9a1bff317c64aff2e

Tukur, S. A., Dambatta, M. S., Ahmed, A., & Mu’az, N. M. (2014). Effect of Heat Treatment Temperature on Mechanical Properties of the AISI 304 Stainless Steel. International Journal of Innovative Research in Science, Engineering and Technology (IJSER), 3(2), 1-8.
